Verve® Fixed
Overview
The Verve® Fixed screen is ideal for balcony situations when static screening is required. This product acts as a static screen for sun control capabilities, privacy screening or as a separating wall. Where required this can be engineered to meet balustrade loadings for balconies. A range of Louvre blade profiles or infills can be selected and used in vertical or horizontal applications as well as fixed or operable to suit the architectural requirements of your project.
Range
Verve® E60
Verve® E90
Verve® B40/25
Verve® B100/50
Verve® B150/50
Verve® B80/40
Verve® B140/40
Verve® Perforated
Verve® Image Perforated
Verve® Lasercut
Span Clarification
- Spans provided are based on generic wind pressure of 1 KPa. Please contact our team if you require project specific wind pressures or terrain categories
- Spans provided are an indicative guide and are subject to the building location and applied wind speeds
- Spans provided are based on average end fixity value and subject to final connection detail
- Where products are also acting as a balustrade, span capacity will be reduced.
- Spans are provided where the product is used standalone, where additional products are connected, span capacity may be reduced.
- For detailed span information, contact Arcadia 1300 458 458 or email sales@arcadia.com.au
Features
Get the most out of your Apartment Balcony
Verve® fixed sun screens deliver numerous benefits such as Passive sun control, inlet light control, glare reduction, Wind barriers and privacy and screening. Incorporating Verve Balcony louvre screens enables greater use of outdoor balconies and increase the sustainability and functionality of buildings. Arcadia range of Fixed, Sliding, Bifolding and Operable products ensures there is a solution for your project. It is important that when selecting balcony screens, an engineered and compliant product is selected due to the intense wind loadings and high levels of exposure - Verve sunscreens have been designed with engineering at the forefront and Arcadias proprietary framing structure, rolling system, tracks and coatings are rigorously tested and build to last.
Living Sustainably
Using Verve® sunscreens improves the sustainability and energy efficiency outcomes of your project. The incorporation of sun shading into the external glazing of a building means that the heat conduction and solar radiation in to the building are greatly reduced and therefore the building’s energy efficiency is increased. Our range of Operable Systems also ensures inlet light and solar gain can be taken advantage of in the winter months
Factors to Consider
Typically the Arcadia Verve® system is top hung with the top track being fixed to the soffit/structure. It is imperative that adequate substrate is included in the building design at early stages to ensure sufficient structure and engineering requirements can be achieved. Our Design and Engineering Team are available to assist architects and designers looking to integrate these products into building designs. It is critical to the operation and installation of the Verve® sliding and bi-folding screens that the substrates are level, straight and correctly aligned with each other. Arcadia has inbuilt tolerance system to cater for certain tolerances, however our Design Team can assist in early stages to achieve a buildable design while accommodating the challenge of sloping balconies, drainage, integration with flooring and balustrades.
Adding the natural beauty of Timber
Arcadias innovative range of Granum Timberlook colours can be applied to our Verve Louvre screen range. Granum timberlook finish is achieved through leading application process that provides a natural wood look, highly durable finish to withstand the harsh climate conditions experienced in Australia. This coating solution is a great way to experience the natural warmth of Timber on apartment balcony screens without the hassle of maintenance experienced on real Timber. Designers can select from an endless collection of colours and finishes to perfectly complement creative architectural designs. Our collection of timbergrains and colours are Australian Standard Compliant, sustainable, durable, and are guaranteed with a long-term warranty.
Applications
